Features

Technical Specification

General

IT Available Space

8~48 Cabinets Per Module

IT Load capacity

20~200kW

Single cabinet power density

3~10kW/Rack

Layout

Single row, double row

Maximum module size

15000*3600*2600mm（W*D*H）

Environmental Adaptability

Ambient Temperature

0~40℃

Relative Humidity

5%~95%

Elevation

0~3000m

Degree of Protection

IP20

Structural System

Cabinet Dimension

W : 600mm, 800mm

D : 1000mm, 1100mm, 1200mm

H : 2000mm, 2200mm

Load Bearing Capacity

1200kg

Cabling Mode

Above or Below

Airtight Container

Cold aisle closed, hot aisle closed, hot and cold aisle closed

Power Supply & Distribution System

Power

380VAC@50Hz

Power Supply Path

Single/Dual

Power Distribution Architecture

2N

UPS

120kVA~800kVA

UPS Type

 Tower, modular

Battery type

Lead-Acid Battery

Backup time

15min

PDU

Input: 16A single-phase, 32A single-phase, 16A three-phase Output: 20 * C13 + 4 * C19

Cooling System

Cooling capacity

Air cooling: 12.5kW, 25kW, 37kW

Chilled water: 20kW, 30kW, 60kW

Installation Type

In row

Refrigerant

Eco Friendly refrigerant R410A

Redundant design

N + 1, 2N

Intelligent Management System

Host Monitor

1U rack type

Monitoring objects

UPS, distribution box, air conditioning, temperature and humidity, smoke, water leakage, Magnetic Door, Access

Notification Mode

SMS, Email, APP

DCIM server

Dual rack server

DCIM basic functions

2D, 3D display, report, alarm, authority management

DCIM high-order function

Asset management, capacity management, Temperature Mapping
