Ultra-large Capacity
·25.6Tbit/s Cross-connect Capacity for service grooming and dispatching.
·400G backplane bandwidth per slot to support 100G/200G/400G data rate.
·40/48 to 80/96 wavelengths scalable transmission capability for SMF.
Excellent Security and Reliability
·Multiple network-level protection schemes and ASON/GMPLS network management capability to protect services
·Comprehensive equipment protection for power supply devices, fans, and system control board 1+1, and cross-connection resource pools..
High Maintainability
·Support statistical analysis and automatic optimization on performance parameters including optical power, OSNR and error rate (Q value). The system will generate reports and optimize them automatically
·Support optical channel power automatic balance, automatic optimization, automatic compensation, and automatic card discovery to lower the cost of maintenance
·Support standard G.709 interface and provides abundant OTN overhead for wavelength services
·Support 1588V2 time and frequency synchronization protocol
·Provide physical layer clock synchronization and Ethernet time synchronization
·Advanced IAMS for network performance supervision, fault isolation, degradation precaution
·Advanced tool OTN Planer for network planning and simulation
Excellent Stability
·Ultra-long haul and ultra-long span transport
·Support FEC, super FEC, PM-QPSK technology
·Support distributed Raman amplification technology
·Monitor and self-adaptive adjustment for power, dispersion, OSNR and Q value
Full Service Bearing
·STM-1/4/16/64/256,
·OC3/12/48/192/768,
·FE/GE/10GE/40GE/100GE,
·FC100/200/400/800/1200,
·OTU1,OTU2,OTU3,OTU4,
